DWR-X2000

• IEEE 802.11 b/g/n/ac/ax

• 6x 5G/4G Internal Antenna, 2x 2.4GHz/5GHz Internal Antenna

N/A

• 2.4 GHz , 5 GHz

N/A

• Device&SIM info, IPv4/IPv6 Dual stack support
• Port forwarding, Dynamic DNS
• UPnP SMS/PIN/APN Management
• SIM Lock
• Syslog
• FOTA upgrade
• TR-069

N/A

N/A

• ROM: 512MB (NAND) / RAM: 512MB (DDR3)

• Power indicator
• 5G network indicator
• Wi-Fi indicator
• Eth indicator

• 1x Gigabit Ethernet WAN/LAN Ports
• 1x 4FF SIM Slot

NONE

• 1x Reset Button

• 1x Power/WPS Button

• 4G LTE : FDD: B1, B3, B5, B7, B8, B20,B28 TDD: B34, B38, B39, B40, B41
• 5G NR : FDD: n1, n3, n5, n7, n8, n20, n28 TDD: n38, n40, n41,n77,n78, n79
• 5G SA max data rate DL up to 2.0Gbps and UL 1Gbps
• 5G NSA-ENDC max data rate DL up to 2.6Gbps and UL 575Mbps
• LTE FDD max rate DL up to 600Mbps and UL 150Mbps

• Router

• Web UI
• SNMP
• TR-069

• IP/MAC Address Filtering, Port Forwarding, Wi-Fi Black/White list

• PP2P, L2TP, IPSec

• IPv6 Dual stack support

• Next generation 5G connectivity speeds up to 2.6 Gbps
• Built-in Wi-Fi6 AX1800 distributes high-speed, high-performance Wi-Fi to all your connected devices2
• Supports multiple 5G bands for increased connectivity options on NSA and SA modes3
• Worldwide Sub-6 5G and LTE-A coverage
• Dual-band Wi-Fi on Standard IEEE 802.11ax, OFDMA and MUMIMO technology makes 4K streaming, VR gaming or video chatting a breeze
• Continuous system maintenance and function upgrade (FOTA)

N/A

N/A

• AC 100V~240V, 50Hz~60Hz 12VDC/1.5A

NONE

• <18W

• Operating Temperature : 0 to 45 °C
• Storage Temperature : -20 to 70 °C
• Operating Humidity : 10% to 95% non-condensing
• Storage Humidity : 5% to 95% non-condensing

• CE

• 5G AX1800 Wi-Fi6 Router
